Siemens HMI Touch Screen Operator Interface 6AV2124-0MC01-0AX0
Siemens HMI Touch Screen Operator Interface 6AV2124-0MC01-0AX0
Couldn't load pickup availability
Siemens 6AV Series Product Description
The Siemens 6AV series is the core hardware line of its SIMATIC HMI (Human Machine Interface) products, used primarily in industrial automation to enable interaction, monitoring, and control between people, machines, and processes.
The series covers a wide range of panels, from basic to high‑end, and can be grouped into the following main categories:
| Product Series | Core Positioning & Features | Typical Order Number Prefix | Software Platform |
|---|---|---|---|
| SIMATIC HMI Comfort Panels | High performance, multifunctional, suitable for complex applications. Offered with keypad, touch, or key‑and‑touch operation. | 6AV2124- |
WinCC (TIA Portal) |
| SIMATIC HMI Unified Comfort Panels | Evolution of Comfort Panels with multi‑touch support and a new web‑based operating concept. | 6AV2128- |
WinCC Unified (TIA Portal) |
| SIMATIC HMI Basic Panels | Cost‑effective, meeting basic HMI needs with simplified functionality. | 6AV2123- |
WinCC (TIA Portal) |
| SIMATIC HMI Mobile Panels | Wireless or wired mobile operating units for flexible operation on large machines or production lines. | - | - |
| SIMATIC HMI Industrial Displays | High‑performance industrial displays; some models also function as industrial thin clients. |
6AV2124- (some models)
|
- |
💎 Core Features & Technical Specifications
Across the 6AV series, the following common technical characteristics apply:
-
Display & Interaction: Generally feature high‑resolution TFT colour widescreen displays with up to 16 million colours. Interaction technologies include resistive, capacitive, and multi‑touch.
-
Industrial Design: High ingress protection ratings – front panels are typically IP65, with some models reaching IP66. Wide operating temperature ranges, e.g. from -30°C to 60°C.
-
Rich Interfaces & Protocols: Typically equipped with PROFINET, Ethernet, USB, and other ports. Wide support for communication protocols such as TCP/IP, PROFIBUS, MODBUS, and EtherNet/IP.
-
Powerful Software Functions: Support for online language switching (up to 32 languages), recipe management, and password protection (up to 50 levels). High‑end models can serve as industrial thin clients with remote desktop protocols like RDP and VNC.
🔢 Order Number Structure & Selection Guide
Siemens 6AV order numbers follow a systematic pattern. Understanding this helps quickly identify the product type:
-
6AV2124-...: Typically Comfort Panels. Example:6AV2124-0GC13-0AX0is a 7‑inch touch panel. -
6AV2128-...: Typically Unified Comfort Panels. Example:6AV2128-3GB06-0AX1is a 7‑inch Unified panel. -
6AV2123-...: Typically Basic Panels. Example:6AV2123-2JB03-0AX0is a KTP900 PN touch panel. -
6AV6647-...,6AV6648-...: Often found in earlier panels or models for specific markets, such as the SMART series. -
6AV6...: A broader range that may include some discontinued classic panels, e.g. OP, TP, and MP series.
